Conducted Disturbance ES-TS120电磁注入钳主要应用于射频场感应的传导骚扰抗扰度和骚扰功率等测试，采用特殊的磁性材料，具有插入损耗小，注入效率高的特点。
1、频率范围：150kHz~300MHz
2、最大线径：20mm
3、适用于任意信号线试验
4、80%AM幅度调制情况下，支持10Vrms测试需求
5、工艺精致
| 频率范围 | 150kHz~230MHz |
| 插入损耗 | ＜10dB |
| 线径 | 20mm |
| 阻抗 | 50Ω |
| 最大输入功率 | 0.15MHz-100MHz: 100W for 15min |
| 100MHz-230MHz :100W for 3min | |
| 注入接口 | N头 |
| 尺寸 | (长）650mm×（宽）100mm×（高）120mm |
